Flexible mangetic sheet |
Made of isotropic rubber magnet, flexible magnetic sheet can be covered with white PVC, color PVC or self-adhesive on the unmagnetized side, and coated with gloss UV oil or matte UV oil on the magnetized side. Magnet roll sheet are widely used in advertisement. |
|
Character |
General |
Range |
|
Width |
620mm |
<1000m |
|
Thickness |
0.3mm～1.5mm |
0.20mm～10mm |
|
Sheet Size |
A4(21cm*29.7cm) |
Custom design |
|
Pole Gap |
2mm, 2.5mm |
Custom design |
Laminates of Magnetic Sheet
1.Suface treatment of magnetic sheeting usually used with vinyl and self-adhesive tape
2.Plain (no laminate, dark brown both sides)
3.White matt ( gloss) vinyl
4.Colourful matt(gloss)vinyl
5.Self adhesive
6.Other laminate available on request
General Size For Making Custom Printed Magnet
| Product | Surface | Dimension | Application | ||
|---|---|---|---|---|---|
| Length(mm) | Width (mm) | Magnet Thickness |
|||
| sheet | 1.Plain brown, Matt or Gloss UV coating on magnetized side 2.With self adhesive, |
1000 | 700 | 0.3mm 0.4mm 0.5mm 0.7mm 0.8mm |
Mounted with printed arts paper and die cut into different sizes and shapes For making customized magnet |
| 500 | 350 | ||||
| 690 | 510 | ||||
| 620 | 490 | ||||
| 450 | 310 | ||||
| 420 | 305 | ||||
| 620 | 500 | 1.0mm 1.2mm 1.5mm |
For making magnetic souvenirs/magnetic gifts comes with self adhesive |
||
| 430 | 310 | ||||
| 3.With white or colorful PVC Matt or Gloss UV coating on the magnetized side |
450 | 300 | 0.7mm 0.75mm 0.8mm |
For making magnetic signs, such as car sign and trafic sign for outdoor applications |
|
| 600 | 300 | ||||
| 600 | 450 | ||||
| Roll | 1.Plain brown, Matt or Gloss UV coating on magnetized side |
30M/15M | 620 | 0.3mm 0.4mm |
Mounted with printed arts paper and die cut into different sizes and shapes |
| 30M/15M | 700 | ||||
| 30M/15M | 1520 | ||||
| 2.With self adhesive, Matt or Gloss UV on Magnetize side |
30M/15M | 620 | 0.3mm 0.4mm 0.5mm 0.6mm 1.0mm |
For making customized magnet |
|
| 30M/15M | 1000 | ||||
| 30M/15M | 1220 | ||||
| 3.With white or colorful PVC Matt or Gloss UV coating on the magnetized side |
30M/15M | 620 | 0.5mm 0.7mm 0.75mm 0.8mm |
For making magnetic signs, such as car sign and trafic sign for outdoor applications |
|
| 30M/15M | 1000 | ||||
| 30M/15M | 1250 | ||||
| Huge Roll |
1.Plain brown, Matt or Gloss UV coating on magnetized side2.With self adhesive, Matt or Gloss UV on Magnetized side |
600M | 315 | 0.4mm 0.5mm 0.6mm 0.8mm |
For making magnetic printed magnet by Automatic production equipment Roll length is depending on the thickness and the max weight of the roll Longer roll is possible |
| 500M | 310 | ||||
| 450M | 480 | ||||
| 450M | 320 | ||||
| 380M | 480 | ||||
| 380M | 320 | ||||
| 200M | 440 | ||||
| Extrusion Magnetic Strip |
With self adhesive | 30M | 12.7/15/20 /25.4 |
1.5mm | Cut to small pieces and apply to labels, photo magnet, cards and others |
Application Field Of Rubber Magnet
Due to the flexibility and magnetic strength of flexible magnet, it is the ideal material where rigid, brittle, or electrical conductive materials can not be used. It can be mainly used in magnetic attraction devices for the refrigerator, disinfector, furniture door, articles for culture and education, advertising signs, stepping motors, electronic equipments, magnetic therapy apparatus, sensors, household appliances, gifts and children’s toys.
Production Process
Packaging & Delivery
Plain magnetic sheeting
Magnetic sheeting with self-adhesive
Magnetic sheeting with PVC
Patch Magnet
