Magnetic Strip | dowell-flexiblemagnet

Extrusion magnet strip is widely applicable for electric refrigerator door, drinking water machine door, bathroom door, relay, magnetic drawing board, toy, teaching, and so forth. Our extruded magnets have wide vary of range of dimension, good quality and price.

Section Dimension	General Length	Surface Cover	Custom Design
*92.5mm,93mm,12.52.2mm**	50m,60m,100m	Self-adhesive	Size & Shape

Technique Parameter of Refrigerator Door Seal:

Isotropic extruded magnet strip：

Item No	General size （mm）	Generall packing					coated
Item No	General size （mm）	m/roll	Rolls/CTN	CTN size	N.W..	G.W.	coated
1	9×2	60	4 rolls	46×46×12cm	16kg	17kg	Self-adhesive
2	10×2	60	4 rolls	46×46×14cm	17.8kg	19kg	Self-adhesive
3	9×2.5	60	4 rolls	46×46×12cm	20kg	21kg	Self-adhesive
4	10×2.5	60	4 rolls	46×46×14cm	22.2kg	24kg	Self-adhesive
5	8×3	60	4 rolls	46×46×10cm	21.3kg	23kg	Self-adhesive
6	9×3	60	4 rolls	46×46×12cm	24kg	25kg	Self-adhesive
7	10×3	50	4 rolls	46×46×14cm	22.2kg	24kg	Self-adhesive
8	11×3	50	4 rolls	46×46×15cm	24.4kg	26kg	Self-adhesive
9	9.8×3.1	50	4 rolls	46×46×14cm	22.5kg	24kg	Self-adhesive
10	12×3.4	50	2rolls	38×38×14cm	22.2kg	24kg	Self-adhesive
11	9×3.5	50	4 rolls	46×46×12cm	23.3kg	25kg	Self-adhesive
12	8×4	50	4 rolls	46×46×12cm	23.7kg	25kg	Self-adhesive
13	10×5	50	2rolls	46×46×12cm	18.5kg	20kg	Self-adhesive

Item	Spe.(mm)	Magnetism Density(mt)	Absorption Force		Crackless Curling Column Diameter(mm)
Item	Spe.(mm)	Magnetism Density(mt)	Absorption Weight(g)	Standard Weight(g)	Crackless Curling Column Diameter(mm)
1	2×9	≥56	29	74	≤20
2	2×10	≥56	32	81	≤20
3	2.5×9	≥64	31	79	≤22
4	2.5×10	≥64	34	87	≤22
5	3×8	≥68	32	81	≤25
6	3×9	≥68	33	84	≤25
7	3×10	≥70	36	92	≤25
8	3×11	≥70	40	102	≤25
9	3.1×9.8	≥70	36	92	≤25
10	3.4×12	≥72	46	117	≤30
11	3.5×9	≥76	35	89	≤30
12	4×8	≥76	32	81	≤30
13	5×10	≥78	40	102	≤30

Packaging & Delivery
